Parallel Twin Screw PVC Profile Extruders
Features Minimizes Energy Inputs Achieves Uniform Pumping
Features
- Minimizes energy inputs
- Achieves uniform pumping
- Minimizes wear & tear
- Economic replacement option
- PID digital temperature controllers
- High accuracy
- Hard face coating on selected models
- PLC controls as standard on select models
Technical Specifications
| Extruder Models | PET 52/18-120 | PET 52/22-150 | PET 52/25-170 | PET 65/18-200 | PET 65/22-250 | PET 68/28-350 | PET 90/22-450 | PET 90/25-550 | PET 92/28-700 |
|---|---|---|---|---|---|---|---|---|---|
| L/D Ratio | 18:1 | 22:1 | 25:1 | 18:1 | 22:1 | 28:1 | 22:1 | 25:1 | 28:1 |
| Main Drive KW - AC | 11 | 15 | 15 | 22 | 30 | 37 | 55 | 55 | 75 |
| Output In KG/HR | 100 TO 120 | 130 TO 150 | 150 TO 170 | 180 TO 200 | 200 TO 250 | 300 TO 350 | 400 TO 450 | 500 TO 550 | 650 TO 700 |
